I. The major performance and structural feature

*Imported PLC computer control system with human-machine interface; touch screen is simple and direct-viewing in operation;

*precise positioning with servo film transporting system; excellent complete machine performance and nice packing;

* minimize the loss with complete automatic warn protection function;

 * supported with metric device, the machine will automatically complete all packaging processes from measuring, feeding, filling, bag making and sealing

* The way of bag making: the machine can make pillow-type bag and standing bag according to customer’s requirements.

 II Technical parameter:

 Packing speed 25-30 bags/min

Bag size (L)50-300mm (W)60-200mm

 Bag making mode Pillow-type bag, standing bag, pounch Range of measuring 150-1300ml

 The maximum width of packing film 420mm

Thickness of film 0.04-0.08mm

Air consumption 0.4m³/min 0.6MPa

Main power/voltage 2.2KW/220V 50-60Hz

Dimension L1400*W950* H1600mm
